Electronic leak detectors

Inficon electronic leakage detector D-TEK select complete

Order No.: 417.3116
Manufacturer number: 712-202-G11
Manufacturer: Inficon


One click to the most important information:

Description

D-Tek Select leak detector, complete with rechargeable batteries, carry case, Tragekoffer,12V cable with cigarette lighter plug, replacement tip/filter kit and 230 V mains plug. The sensitivity of the D-TEK Select is maintained over a long period of time so that you can expect consistent, ...

D-Tek Select leak detector, complete with rechargeable batteries, carry case, Tragekoffer,12V cable with cigarette lighter plug, replacement tip/filter kit and 230 V mains plug. The sensitivity of the D-TEK Select is maintained over a long period of time so that you can expect consistent, precise and reliable performance even when detecting newer refrigerant mixtures. The main advantage, however, is that the measuring cells last for around 800 to 1000 hours - almost ten times longer than the sensor of the D-TEK -. This means your overall operating costs are reduced and your productivity increased. Further improvements are the battery charge indicator, a sensor failure indicator and NiMH (nickel metal hydride) batteries. All these functions are brought together in one user-friendly device that stands out for the quality and durability you have come to expect from INFICON.

show more


Features

  • Sensitivity of 1g/year
  • High-efficiency air pump for short response times and fast drainage (“zeroing”)
  • Power supply: NiMH battery pack for 6.5 hours operation
  • Charging option: 220 V mains adapter
  • Integrated charger
  • Sensitive to all refrigerants
  • No reduction in sensitivity of the infrared cell ...
  • Sensitivity of 1g/year
  • High-efficiency air pump for short response times and fast drainage (“zeroing”)
  • Power supply: NiMH battery pack for 6.5 hours operation
  • Charging option: 220 V mains adapter
  • Integrated charger
  • Sensitive to all refrigerants
  • No reduction in sensitivity of the infrared cell over time

Suitable for the following refrigerants: R22, R134a, R404a, R410a, R448a, R507 (AZ-50), R32, HFO1234yf, SF6, an all other CFCs, HCFCs, HFCs and HFOs

show more


Scope of delivery

  • D-Tek Select leak detector
  • Complete with rechargeable batteries, carry case
  • 12 V cable with cigarette lighter plug
  • Replacement tip/filter kit
  • 230 V mains plug

Accessories / Replacement parts

  • Cable for cigarette lighter
    Inficon charging cable 12V automotive f. D-TEK Select + CO2 703-055-P1
    Order No.: 417.3108
  • Carry case
    Inficon carry case f. D-TEK Select 712-702-G1
    Order No.: 417.3119
  • Filter
    Inficon filter cartridge f. D-TEK Select + CO2 712-707-G1
    Order No.: 417.3122
  • Replacement charger
    Inficon charger 230V w. cable 1,8m f. D-TEK Select + CO2 033-0020-G1
    Order No.: 417.3135
  • Replacement rechargeable battery
    Inficon rechargeable battery NiMH-Stab f. D-TEK Select + CO2 712-700-G1
    Order No.: 417.3117
  • Replacement sensor
    Inficon infrared sensor f. D-TEK Select 712-701-G1
    Order No.: 417.3118

Technical data

Dimensions
Probe length
431,8 mm
General information
Sensitivity
1 g/year
Type
D-Tek Select
Weight
Total
540 g
Temperature data
Operating temperature
-25 bis +50 °C
Storage temperature
-10 bis +60 °C
Technical modifications reserved. Product images may differ from the actual product and are meant for demonstration purposes only. Absolutely no liability can be assumed for possible indication errors and errors in the manufacturers’ information.
