Reciprocating piston

Bock semi-hermetic compressor R134a HGX 6/1410-4 400V/3/50Hz

Order No.: 102.5432

Manufacturer number: 14738

Manufacturer: Bock / Danfoss

One click to the most important information:

Accessories / Replacement parts
Technical data

Accessories / Replacement parts
Technical data

Accessories / Replacement parts

Additional ventilator

Bock additional fan 230V HG(X)4+5+6

Order No.: 102.4821
Crankcase heater

Bock oil sump heating-BS 230V replacement 140W f.HA/HG(X)5/6/7, F6/F14+16 08426

Order No.: 102.4838
Oil pressure safety switch

Bock oil differential pressure switch BS 230V MP54 f. HG(X)4-7 HG(X) 44e

Order No.: 102.4668
Oil servicing valve

Bock oil service valve HA/HG(X)5+6 mounted

Order No.: 102.4611
Bock oil service valve HA/HG(X)4-8 replacement 07946

Order No.: 102.4913
Thermal protection thermostat

Bock thermal protection thermostat HA/HG(X)22+34, 4 till 8

Order No.: 102.4614

Technical data

Type

HGX6/1410-4

Cylinder

Power consumption

18.60 kW

refrigerant=R 134A, evaporating temperature=12.5 °C, condensation temperature=30 °C

18.10 kW

refrigerant=R 134A, evaporating temperature=10 °C, condensation temperature=30 °C

17.50 kW

refrigerant=R 134A, evaporating temperature=7.5 °C, condensation temperature=30 °C

17.00 kW

refrigerant=R 134A, evaporating temperature=5 °C, condensation temperature=30 °C

15.80 kW

refrigerant=R 134A, evaporating temperature=0 °C, condensation temperature=30 °C

14.60 kW

refrigerant=R 134A, evaporating temperature=-5 °C, condensation temperature=30 °C

13.30 kW

refrigerant=R 134A, evaporating temperature=-10 °C, condensation temperature=30 °C

12.00 kW

refrigerant=R 134A, evaporating temperature=-15 °C, condensation temperature=30 °C

10.70 kW

refrigerant=R 134A, evaporating temperature=-20 °C, condensation temperature=30 °C

9.38 kW

refrigerant=R 134A, evaporating temperature=-25 °C, condensation temperature=30 °C

8.04 kW

refrigerant=R 134A, evaporating temperature=-30 °C, condensat

Supply voltage

400/3/50 V/Ph/Hz

max. starting current

193 A

max. operating current

55 A

Weight net

220 kg

Refrigerating capacity

113000 W

refrigerant=R 134A, evaporating temperature=12.5 °C, condensation temperature=30 °C

103000 W

refrigerant=R 134A, evaporating temperature=10 °C, condensation temperature=30 °C

93100 W

refrigerant=R 134A, evaporating temperature=7.5 °C, condensation temperature=30 °C

84500 W

refrigerant=R 134A, evaporating temperature=5 °C, condensation temperature=30 °C

68900 W

refrigerant=R 134A, evaporating temperature=0 °C, condensation temperature=30 °C

55400 W

refrigerant=R 134A, evaporating temperature=-5 °C, condensation temperature=30 °C

44000 W

refrigerant=R 134A, evaporating temperature=-10 °C, condensation temperature=30 °C

34300 W

refrigerant=R 134A, evaporating temperature=-15 °C, condensation temperature=30 °C

26400 W

refrigerant=R 134A, evaporating temperature=-20 °C, condensation temperature=30 °C

19900 W

refrigerant=R 134A, evaporating temperature=-25 °C, condensation temperature=30 °C

14800 W

refrigerant=R 134A, evaporating temperature=-30 °C, conde

Pressure line

35 / 1 3/8

mm/inch

Suction line

54 / 2 1/8

mm/inch

Oil quantity

4,5 l
