Charles Austen condensate pump Maxi Blue-D with DrainStik

Order No.: 772.3445
Manufacturer number: X87-702
Manufacturer: Charles Austen

More in this category: Condensate pumps

One click to the most important information:

Description

The MaxiBlueTM condensate pump is a rotation membrane pump in the BlueDiamond range for use in split air conditioning systems with a power rating of up to 10 kW and guarantees reliable, uninterrupted operation. The MaxiBlueTM is slim enough to cable ducts, powerful enough for remote ...

The MaxiBlueTM condensate pump is a rotation membrane pump in the BlueDiamond range for use in split air conditioning systems with a power rating of up to 10 kW and guarantees reliable, uninterrupted operation. The MaxiBlueTM is slim enough to cable ducts, powerful enough for remote installation and quiet enough for installation into false ceilings.

The pump unit consists of the pump itself with inlet and outlet nozzles (7.8 mm external diameter), universal adapters for attaching to the drainage line, the internal control circuit, the power supply and a three-core mains cable (2 m).

Version:
MaxiBlueTM with DrainStikTM:
The DrainStikTM features semiconductor fill level sensors for high/low level as well as a sensor for the alarm contact. The DrainStikTM can be installed in the condensation drain hose for all common devices directly or using an adapter.

show more


Features

  • Entirely self-priming up to 8 m
  • No float, no valves or filters - maintenance-free
  • Silent and vibration-free operation
  • Can safely run dry *
  • Problem-free pump down of contaminants
  • CE mark

* Dry operation for long periods can reduce the life of the pump


Accessories / Replacement parts

  • Condensate hose
    Sauermann PVC hose ACC00911 roll 25m inner diameter 10mm
    Order No.: 722.4495
  • PVC hose Raufilam E (bundle = 50m) food quality according to BGA1 8.0x3.0mm
    Order No.: 722.3456
  • Pressure hose (Raufilam) (bundle = 50m) f. condensate pump 6 mm diameter
    Order No.: 722.3433
  • Sauermann PVC hose ACC00910 roll 50m inner diameter 6mm
    Order No.: 722.4488
  • Connection adapter/outlet nozzles
    Aspen Xtra connection adapter PVC reduction 6/10mm (Pack=3pcs) FP2040
    Order No.: 772.3495
  • Sauermann drain socket 6mm & 10mm - 3/4" and 40mm (1pc)
    Order No.: 722.4528
  • Aspen Xtra connection adapter drainage nozzle 6/10mm (Pack=3pcs) FP2038
    Order No.: 772.3494
  • Connector
    Aspen Xtra hose connection piece PVC connector 16mm (Pack=5pcs) FP2058
    Order No.: 772.3506
  • Drain stick
    Charles Austen Drain Stik for Maxi/MegaBlue S12-004S
    Order No.: 772.3451
  • Extension
    Charles Austen extension sensor 5m Mini/Maxi/MegaBlue C13-103
    Order No.: 772.3457
  • Mounting lugs
    Charles Austen mounting brackets Mini/Maxi/MegaBlue F10-011
    Order No.: 772.3456
  • Muffler
    Charles Austen muffler S09-036
    Order No.: 772.3505
  • Multi tank
    Charles Austen Multi Tank Maxi/MegaBlue C21-014
    Order No.: 772.3455
  • Tank sensor
    Charles Austen tank sensor for Mini/MaxiBlue C21-013
    Order No.: 772.3452
  • Temperature sensor
    Charles Austen temperature sensor f. Mini/Maxi/MegaBlue S12-002
    Order No.: 772.3450
  • Universal adapter
    Charles Austen universal adapter rigid f. Mini-/Maxi-/Mega Blue C01-226
    Order No.: 772.3459
  • Charles Austen universal adapter flexible f. Mini-/Maxi-/Mega Blue C01-227
    Order No.: 772.3460

Technical data

Dimensions
Pump module (L x W x H)
155 x 59 x 68 mm
General information
Type
MaxiBlue-DTM
Connections
Tube connection
Outer diameter
7,8 mm
Electrical Data
Supply voltage
230/1/50 V/Ph/Hz
braun: stromführend an L
blau: neutral an N
grün/gelb: an Erde
Weight
Weight net
0,7 kg
Performance data
max. suction lift
8 m
max. delivery head
8 m
max. conveying capacity
14 l/h
Sound data
Sound pressure level
21 dB(A)
Technical modifications reserved. Product images may differ from the actual product and are meant for demonstration purposes only. Absolutely no liability can be assumed for possible indication errors and errors in the manufacturers’ information.
