Condensate pumps

Aspen Tauwasserpumpe Silent+ Mini Orange Gen. 5

Order No.: 772.3718

Manufacturer number: FP3430

Manufacturer: Aspen

To previous product 772.3436

Description

Silent+ Mini Orange condensation water pump; 230V / 50Hz. The Silent+ features a high-performance motor, a silencer, vibration-damping pipes and is ideally suited for offices or conference rooms. It has an open container as well as a pre-assembled anti-lifting effect valve. The pump is ...

Features

Additional vibration dampers = significantly quieter installation
Anti-vibration pressure hose
Innovative pump cores made of high temperature plastic guarantee minimum noise
Universal solution up to 16 kW

Scope of delivery

Silent+ Mini Orange pump
1.5m Plug & play power cable
Acoustic damper and 1m orange discharge tube with connector
Anti vibration bracket
Reservoir
Reservoir lid with 1.5m sensor cable
Submersible reservoir
Anti siphon device
Float & filter
1.5m Suction tube 6mm ID
220mm Orange inlet ...

Accessories / Replacement parts
Technical data

Accessories / Replacement parts

Accessories/replacement parts

Aspen Verlängerungskabel für Mini Orange Länge 10m

Order No.: 772.3734
Aspen Verlängerungskabel für Mini Orange Länge 5m

Order No.: 772.3733
Condensate hose

Sauermann PVC hose ACC00910 roll 50m inner diameter 6mm

Order No.: 722.4488
Sauermann PVC hose ACC00911 roll 25m inner diameter 10mm

Order No.: 722.4495
Connection adapter/outlet nozzles

Aspen Xtra connection adapter PVC reduction 6/10mm (Pack=3pcs) FP2040

Order No.: 772.3495
Sauermann drain socket 6mm & 10mm - 3/4" and 40mm (1pc)

Order No.: 722.4528
Aspen Xtra connection adapter drainage nozzle 6/10mm (Pack=3pcs) FP2038

Order No.: 772.3494
Connector

Aspen Xtra hose connection piece PVC connector 16mm (Pack=5pcs) FP2058

Order No.: 772.3506
Service case

Aspen Xtra Toolbox hose fittings 60 parts,

Order No.: 772.3477

Technical data

Width

37,9 mm

Height

65,7 mm

Length

144,9 mm

Float module (L x W x H)

108x40x43 mm

Connectable indoor units

Wandgeräte, Kanalgeräte, Bodenkonvektoren, Deckenkassetten

Type

Schwingkolbenpumpe

Sensor

Füllstandssensor

Type

Silent+ Mini Orange

Supply voltage

230/1/50 V/Ph/Hz

max. safety switch

5.0 A.N.C. (Öffnerkontakt)

max. delivery head

10 m

max. conveying capacity

30 l/h

max. power

40 kW

Sound pressure level

16 dB(A)

Unter der Annahme einer Massivwandkonstruktion mit einem 2kW-Gerät
