Parker ZoomLock braze-free fitting coupling PZK-C4-HNBR 1/4''

Order No.: 313.280001
Manufacturer number: 770500
Manufacturer: Sporlan / PARKER

More in this category: Couplings

One click to the most important information:

Description

The ZoomLock™ pipe connection system is an innovative system for joining pipes without the use of solder and is suitable for any refrigeration and air conditioning application. Pipes can be joined with a simple tool and using minimal force.

ZoomLock™ fittings allow properly sealed ...

The ZoomLock™ pipe connection system is an innovative system for joining pipes without the use of solder and is suitable for any refrigeration and air conditioning application. Pipes can be joined with a simple tool and using minimal force.

ZoomLock™ fittings allow properly sealed pipe connections to be made without using solder, making it much faster and easier to join copper pipes. These single-piece fittings also stay reliably in place, are leak-proof and offer better reproducibility than solder connections - meaning no compromise needs to be made on quality or functionality.
The time needed and costs of work for connecting pipes are significantly reduced by not having to solder. Solder-free pipe connections increase productivity, profit potential and offer numerous other advantages.

show more


Features

  • Vibration-resistance: Corresponds to UL109
  • Available sizes (inch): 1⁄4", 5⁄16", 3⁄8", 1⁄2", 5⁄8", 3⁄4", 7⁄8", 1.1⁄8", 1.3⁄8"
  • Fitting body: Refrigerant-resistant copper according to ASTM-B280
  • O-ring: HNBR
  • Approved oils: Mineral oil, POE, PVE, PAG
  • Approved pipe materials: ...
  • Vibration-resistance: Corresponds to UL109
  • Available sizes (inch): 1⁄4", 5⁄16", 3⁄8", 1⁄2", 5⁄8", 3⁄4", 7⁄8", 1.1⁄8", 1.3⁄8"
  • Fitting body: Refrigerant-resistant copper according to ASTM-B280
  • O-ring: HNBR
  • Approved oils: Mineral oil, POE, PVE, PAG
  • Approved pipe materials: Copper-copper joins
  • Approved copper pipe types for use with Klauke® compatible press clamps:
    • Hard copper (drawn) 1⁄4"–1.1⁄8" type ACR, M, L- type K only up to 7⁄8"
    • Soft copper (annealed) 1⁄4"–1.1⁄8" type ACR, L - type K only up to 7⁄8"
  • Approved copper pipe types for use with RIDGID® compatible press clamps:
    • Hard copper (drawn) 1⁄4"–1.3⁄8" type ACR, M, L - type K only up to 1.1⁄8"
    • Soft copper (annealed) 1⁄4"–1.3⁄8" type ACR, L - type K only up to 1.1⁄8"
  • Approved refrigerants
    • 1234yf, 1234ze, 125, 32, 134a, 143A
    • 404A, 407A, 407C, 407F, 410A, 438A
    • 447A, 448A, 449A, 450A, 452A
    • 507, 513A

show more


Vorteile

  • Weniger Ausrüstung und kein Gas erforderlich
  • Sicheres Arbeiten, keine Brandgefahr
  • Keine Genehmigungen für Lötarbeiten erforderlich
  • Umweltfreundlicher
  • Keine Qualitätsprobleme durch Lötfehler
  • Flexiblerer Zugang zum Installationsort
  • Keine Stickstoffspülung nötig

Technical data

General information
Construction
Muffe
Installation size
1/4 Zoll
Rohrmaß
zöllig
Type
PZK-C4-HNBR
Pressure
Bursting pressure
207 bar
max. operating pressure
48 bar
Temperature data
Working temperature range
-40 bis +148,9 °C
Operating temperature
121 °C
Technical modifications reserved. Product images may differ from the actual product and are meant for demonstration purposes only. Absolutely no liability can be assumed for possible indication errors and errors in the manufacturers’ information.
