Condensate pumps

Sauermann condensate pump (peristaltic) PE 5200 230V max.6L/h.

Order No.: 722.4449
Manufacturer number: PE5200SIUN23
Manufacturer: Sauermann

More in this category: Condensate pumps

One click to the most important information:

Description

PE 5100 peristaltic pump; controlled by an external float switch, 230V / 50 Hz. This peristaltic pump is controlled by the separate float switch with the switching points On, Off, Alarm. The alarm contact is de-energised when closed and should be used to switch off the air conditioning unit or ...

PE 5100 peristaltic pump; controlled by an external float switch, 230V / 50 Hz. This peristaltic pump is controlled by the separate float switch with the switching points On, Off, Alarm. The alarm contact is de-energised when closed and should be used to switch off the air conditioning unit or a solenoid valve if there is an imminent risk of condensate overflow.

show more


Features

  • Easy installation, no ventilation required
  • Easy maintenance (hydraulic head exchangeable, peristaltic hose easily accessible and easy to change)
  • Low running noise
  • Large discharge head
  • With alarm function

Scope of delivery

  • Peristaltic pump PE 5200
  • Power cable 1.7 m: 2 wires (phase, neutral)
  • Cable for alarm contact 1.7 m long, 2-wire
  • Easy to mount, adjustable bracket
  • Sensor block with float switch (SI2958, cable 1.5 m)
  • Installation kit for sensor: rubber hose Ø 15 x 35, ventilation pipe Ø 4 x 6 (75 mm) and ...
  • Peristaltic pump PE 5200
  • Power cable 1.7 m: 2 wires (phase, neutral)
  • Cable for alarm contact 1.7 m long, 2-wire
  • Easy to mount, adjustable bracket
  • Sensor block with float switch (SI2958, cable 1.5 m)
  • Installation kit for sensor: rubber hose Ø 15 x 35, ventilation pipe Ø 4 x 6 (75 mm) and self-adhesive mounting rail

show more


Accessories / Replacement parts

  • Condensate hose
    Sauermann PVC hose ACC00910 roll 50m inner diameter 6mm
    Order No.: 722.4488
  • Sauermann PVC hose ACC00909 roll 5m inner diameter 6mm
    Order No.: 722.4489
  • Sauermann PVC hose strengthened ACC00914 roll 50m inner diameter 6mm
    Order No.: 722.4494
  • Sauermann PVC hose ACC00911 roll 25m inner diameter 10mm
    Order No.: 722.4495
  • Connection adapter/outlet nozzles
    Aspen Xtra connection adapter PVC reduction 6/10mm (Pack=3pcs) FP2040
    Order No.: 772.3495
  • Sauermann drain socket 6mm & 10mm - 3/4" and 40mm (1pc)
    Order No.: 722.4528
  • Aspen Xtra connection adapter drainage nozzle 6/10mm (Pack=3pcs) FP2038
    Order No.: 772.3494
  • Connector
    Aspen Xtra hose connection piece PVC connector 16mm (Pack=5pcs) FP2058
    Order No.: 772.3506
  • Replacement hose
    Sauermann peristaltic hose PE 5002 for PE5000
    Order No.: 722.4448

Technical data

Dimensions
Pump module (L x W x H)
109 x 110 x 91 mm
Float module (L x W x H)
55 x 38 x 36 mm
Electrical Data
Protection class
IP 65
Supply voltage
230/1/50 V/Ph/Hz
Weight
Weight net
ca. 1,25 kg
Performance data
max. suction lift
2,0 m
max. delivery head
12 m
max. conveying capacity
6,0 l/h
Sound data
Sound pressure level
30 dB(A)
Technical modifications reserved. Product images may differ from the actual product and are meant for demonstration purposes only. Absolutely no liability can be assumed for possible indication errors and errors in the manufacturers’ information.
