Sauermann Tauwasserpumpe (Peristaltik) SI 51 Schlauchpumpe 6 l/h

Sauermann Tauwasserpumpe (Peristaltik) SI 51 Schlauchpumpe 6 l/h
Icon. Image similar to product.
Order No.: 722.4548
Manufacturer number: SI51CE01UN23
Manufacturer: Sauermann
To previous product 722.4473

More in this category: Condensate pumps

One click to the most important information:

Description

PE 5100 peristaltic pump; controlled by thermo sensor, 230V / 50 Hz. This peristaltic pump has two thermal sensors. The pump switches on as soon as the temperature difference reaches 6°C. It switches off if the temperature difference is less than 6°C for 3 minutes.

Features

  • Easy installation, no ventilation required
  • Easy maintenance (hydraulic head exchangeable, peristaltic hose easily accessible and easy to change)
  • Low running noise
  • Large discharge head
  • Small dimensions

Scope of delivery

  • Pump PE 5100
  • Power cable 1.7 m: 2 wires (phase, neutral)
  • Cable for the two thermo sensors, 3.5 m long: one with red end piece for ambient air, one with blue end piece for cold air
  • Easy to mount, adjustable bracket (1 fixing screw)
  • Reducer PE5003 for hose inner diameter 15 to 6 mm

Accessories / Replacement parts

  • Condensate hose
    Sauermann PVC hose ACC00910 roll 50m inner diameter 6mm
    Sauermann PVC hose ACC00910 roll 50m inner diameter 6mm
    Order No.: 722.4488
  • Sauermann PVC hose ACC00909 roll 5m inner diameter 6mm
    Sauermann PVC hose ACC00909 roll 5m inner diameter 6mm
    Order No.: 722.4489
  • Sauermann PVC hose strengthened ACC00914 roll 50m inner diameter 6mm
    Sauermann PVC hose strengthened ACC00914 roll 50m inner diameter 6mm
    Order No.: 722.4494
  • Sauermann PVC hose ACC00911 roll 25m inner diameter 10mm
    Sauermann PVC hose ACC00911 roll 25m inner diameter 10mm
    Order No.: 722.4495
  • Connection adapter/outlet nozzles
    Aspen Xtra connection adapter drainage nozzle 6/10mm (Pack=3pcs) FP2038
    Aspen Xtra connection adapter drainage nozzle 6/10mm (Pack=3pcs) FP2038
    Order No.: 772.3494
  • Aspen Xtra connection adapter PVC reduction 6/10mm (Pack=3pcs) FP2040
    Aspen Xtra connection adapter PVC reduction 6/10mm (Pack=3pcs) FP2040
    Order No.: 772.3495
  • Sauermann drain socket 6mm & 10mm - 3/4" and 40mm (1pc)
    Sauermann drain socket 6mm & 10mm - 3/4" and 40mm (1pc)
    Order No.: 722.4528
  • Connector
    Aspen Xtra hose connection piece PVC connector 16mm (Pack=5pcs) FP2058
    Aspen Xtra hose connection piece PVC connector 16mm (Pack=5pcs) FP2058
    Order No.: 772.3506
  • Einfüllflasche
    Sauermann filling bottle ACC00944 for pump check
    Sauermann filling bottle ACC00944 for pump check
    Order No.: 722.4505
  • Replacement hose
    Sauermann Peristaltik Schlauch Ersatzschlauch für SI-50, SI-51 + SI-52
    Sauermann Peristaltik Schlauch Ersatzschlauch für SI-50, SI-51 + SI-52
    Order No.: 722.4546
  • Sauermann peristaltic hose PE 5002 for PE5000
    Sauermann peristaltic hose PE 5002 for PE5000
    Order No.: 722.4448

Technical data

Dimensions
Pump module (L x W x H)
105 x 108 x 122 mm
General information
Type
Si-51
Electrical Data
Protection class
IP55
Supply voltage
230/1/50 V/Ph/Hz
Weight
Weight net
ca. 0,90 kg
Performance data
max. suction lift
2 m
max. delivery head
12 m
max. conveying capacity
6,0 l/h
Sound data
Sound pressure level
bis 30 dB(A)
Technical modifications reserved. Product images may differ from the actual product and are meant for demonstration purposes only. Absolutely no liability can be assumed for possible indication errors and errors in the manufacturers’ information.
