Panasonic PRO HT buffer tank f. heating and cooling water PAW-VP380L
Icon. Image similar to product.
Icon. Image similar to product.
Order No.: 758.2624
Manufacturer number: PAW-VP380L
Manufacturer: Panasonic
More in this category: Buffer tank | Accumulators
One click to the most important information:
Description
The Panasonic PRO-HT tank is suitable for numerous applications and can be used in combination with PACi units e.g. in residential complexes, offices and hotels.
Features
- 380 l storage volume
- Water heating at temperatures up to 60 ° C without an electric heating element
- Stainless steel tank and heat exchanger
- 316L stainless steel coil
- Pickled internally and externally
- 70 mm thermal insulation
- Wall thickness of the tank 2 mm, 316L stainless steel
- External ABS cladding
- 380 l storage volume
- Water heating at temperatures up to 60 ° C without an electric heating element
- Stainless steel tank and heat exchanger
- 316L stainless steel coil
- Pickled internally and externally
- 70 mm thermal insulation
- Wall thickness of the tank 2 mm, 316L stainless steel
- External ABS cladding
Technical data
Dimensions
Outer diameter
690 mm
Height
1820 mm
General information
Container volume
380 l
Energy efficiencyclass
Heating
A+++
bei W35 (Skala von A+++ bis D)
Type
Pufferspeicher
Performance data
COP
3,26
bei +7 °C (A7/W45)
Wasservolumenstrom
3,9 m³/h
(A7/W35)
Pipe connections
Anschluss wasserseitig
1 1/4 Inch
Technical modifications reserved. Product images may differ from the actual product and are meant for demonstration purposes only. Absolutely no liability can be assumed for possible indication errors and errors in the manufacturers’ information.
